1. Signal source function (CH1 and CH2)

1) Output signal: Through the touch screen can set the output with bias sine wave signal, output DC voltage signal, output AC sine wave signal, output square wave signal;

2) Signal frequency setting range: 0.001Hz~20kHz can be set through the touch screen;

Frequency accuracy: ±0.03%

3) Signal amplitude setting range :0 ~10.0V P-P(RMS:0-3.536V) can be set through the touch screen;

Amplitude display resolution: 0.001mv~1mv

4) Bias voltage setting range: -22.0V~+10.0V can be set through the touch screen;

Bias voltage display resolution: 0.01V

5) Signal phase difference setting range: 0~360 degrees can be set through the touch screen;

Two, oscilloscope function:

1) 1 channel oscilloscope function, can display various signal waveforms in real time;

2) The display time and amplitude of the signal waveform can be adjusted through the touch screen;

Three, multimeter function:

1) 1 multimeter function, through the touch screen can choose real-time measurement of voltage signal and current signal;

2) Current measurement range: 0.0mA~65mA

Current display resolution: 0.001mA
